Negative Pressure Ambulance

Negative Pressure Ambulance

This ambulance is refitted on IVECO NJ6556 Euro VI diesel chassis. The medical cabin adopts integrated antibacterial ABS interior, equipped with electric stretcher, dual oxygen supply, independent heating, UV disinfection lamp and 4000W off-grid inverter. It is fitted with professional negative pressure system to block pathogen spread during infectious patient transport. Standard configurations include full LED warning lights, front-rear intercom, GPS and reversing camera. Optional upgrades cover ventilator, defibrillator and 5G telemedicine terminal. Manufactured by Nanjing Gaoli with complete registration certificates, it provides 7×24 after-sales service, widely used in pre-hospital emergency, infectious disease transfer and mass event medical support.

  • Order(MOQ) :

    1 unit

  • Payment :

    Telegraphic Transfer

  • Product Origin :

    Nanjing City, Jiangsu Province

  • Shipping Port :

    Nanjing City, Jiangsu Province

  • Lead Time :

    SHACMAN Delong X5000 Mobile CT Vehicle
Inquiry Now

  • 1. IVECO NJ6556ECM National VI Diesel Chassis

    • Dimension: 5495/5670 × 2040/2060 × 2726/2820/2795 mm
    • Medical cabin inner size: 3000×2100×1800 mm
    • Wheelbase 3300mm, curb weight 3100kg, GVW 4000kg, 2.0T diesel engine (107kW), 5-speed manual transmission, 100L fuel tank.
    • Standard full LED warning light system: roof emergency light, side & rear strobe lights, medical privacy tinted windows, medical red cross livery customizable.

    2. Integrated ABS Medical Cabin Layout

    One-piece seamless ABS interior with rounded corners, anti-bacterial medical floor, easy to disinfect. Zoned functional layout:
    1. Stretcher zone: WSX-AD-2 electric loading stretcher with carbon fiber spare stretcher, quick-release brackets for critical care equipment.
    2. Left medical cabinet group: overhead drug lockers, built-in 10L dual oxygen cylinder system with automatic switch valve.
    3. Right medical staff zone: rear-facing doctor seat + double passenger bench with safety belts, grab handles at middle & rear doors.
    4. Separated partition with observation window & intercom system between cockpit and medical cabin.

    3. Core Negative Pressure Epidemic Prevention System

    500W 220V negative pressure unit with triple monitoring: real-time differential pressure detection, overpressure alarm, filter blockage reminder. One-way airflow design prevents cross infection, ideal for infectious patient transport.

    4. Full Self-contained Power, Temperature & Disinfection System

    • Independent rear heating unit + top air circulation fan for constant cabin temperature.
    • Full LED cabin lighting + timed UV disinfection lamp for post-transport sterilization.
    • 4000W inverter with external municipal power cable, supporting ventilator, defibrillator and all medical devices off-grid.
    • Central electrical control panel with reserved 5G telemedicine interface, GPS & reversing camera for driving safety.

    5. Standard & Optional Medical Devices

    Standard: dual oxygen supply system, electric stretcher, first-aid storage kits, fire extinguisher.

    Optional: Mindray/Comen defibrillator monitor, transport ventilator, CPR machine, video laryngoscope, 5G remote diagnosis terminal.

    6. After-sales Service Advantage

    7×24h after-sales support: 1-hour response, 2-hour on-site arrival, 12-hour fault resolution. Regular free vehicle inspection twice a year, long-term low-cost spare parts supply and vehicle refitting service.

    7. Application Scenarios

    Pre-hospital emergency transfer, infectious disease isolation transport, township medical outreach, mass event medical support, disaster rescue casualty evacuation.
